0.25N.m NEMA17 NEMA-17 17HS3401 DC 12V 1.3A 0.25N.m 1.8 Degree 4 Lead Cables 42BYGH L34mm Stepper Motor For CNC Machine 3D Printer NEMA 17 Stepper Motor

Ratings 0

~~৳1120~~

৳877

Brand : Non_Brand

Color Family

Multi Color

Size Int:

Medium

Stock Quantity:

10

High Holding Torque – 23Ncm for precise movement and control.
Low Power Consumption – 0.42A current per phase for energy efficiency.
Accurate Step Angle – 1.8-degree step angle for fine resolution in movement.
Durable Shaft – D-Cut shaft design for secure coupling with the drive.

Description:

The NEMA 17 Stepper Motor 17HS3401 is a high-performance motor designed for precision control and efficiency.
With a holding torque of 23Ncm, it offers stable and reliable movement for a wide range of applications, including 3D printers, CNC machines, and robotics.
Its 1.8-degree step angle ensures fine resolution and smooth operation, while the D-Cut shaft provides a secure connection to the drive.
The compact 34mm motor length makes it ideal for tight spaces without sacrificing performance.
It features low power consumption with 0.42A current per phase, making it an energy-efficient solution for demanding tasks.

Specifications:

Holding Torque: 23Ncm
Current / Phase: 0.42A
Voltage: 6.72V
Resistance: 16Ω
Inductance: 24mH
Shaft Diameter: 5mm
Shaft Type: D-Cut shaft
Step Angle: 1.8 Degrees
Model Number: NEMA17
Phase: 2
Motor Type: Hybrid
Model: JK42HS34-0424A-02F
Motor Length: 34mm
Diameter of Axle: 5mm

Package:

1 x NEMA 17 Stepper Motor 17HS3401 1.3A

FAQ:

Q1: What is the holding torque of this motor?

The holding torque is 23Ncm, ensuring strong and reliable control.

Q2: What is the current per phase?

The motor operates at 0.42A per phase, offering efficient power consumption.

Q3: What is the step angle?

The step angle is 1.8 degrees, providing fine resolution in stepper movement.

Q4: What type of shaft does the motor have?

The motor has a D-Cut shaft, which provides a secure connection for the coupling.

Q5: How long is the motor?

The motor has a length of 34mm, making it compact and ideal for space-constrained applications.
