380V 30-110 Degrees 50-300 Degrees Three-phase Thermostat Temperature Control Switch Temperature Controller/ Oven Safety Temperature Controller/ Heater Controller
0
Ratings 0
৳1400
Brand : Non_Brand
Color Family
Size Int:
Stock Quantity:
This three-phase thermostat temperature controller offers a wide temperature range of 50°C to 320°C, suitable for various appliances like water heaters, ovens, and more. It features a durable design with an insulation resistance greater than 100MΩ, dielectric strength of 2000V AC for 1 minute, and a long lifecycle exceeding 100,000 cycles. Customizable shell color, logo, and plug options are available to meet specific customer needs.
Thermostat t.max. 300°C temperature range 50-300°C 3-pole 3NO 16A probe ø 6mm probe length 79mm
| Temperature max. | 300 °C |
| Operating temperature range | 50-300 °C |
| Number of poles | 3 -pole |
| Function | 3NO |
| Switching capacity | 16 A |
| Probe diameter | 6 mm |
| Probe length | 79 mm |
| Capillary pipe length | 1740 mm |
| Capillary pipe length insulated | 800 mm |
| Gland nut | - |
| Shaft diameter | ø6x4,6 mm |
| Shaft length | 3 mm |
| Shaft position | upper |
| Rotation angle | 270 ° |
