NodeMcu V3 ESP8266 WIFI Module Development Board with CH340

Ratings 0

~~৳320~~

৳270

Brand : Arduino

Color Family

Black

Size Int:

Small

Stock Quantity:

15

Description:
The NodeMcu V3 ESP8266 WIFI Module Development Board is a powerful development board equipped with the ESP8266 WiFi module. It supports 802.11 b/g/n wireless standards and offers flexible operating modes, including STA, AP, and STA + AP. This board comes with a built-in TCP/IP protocol stack to support multiple TCP client connections, making it ideal for IoT projects. It also includes GPIO, PWM, and IIC support for various applications. With OTA remote firmware upgrades, you can easily update your projects. The module is USB-powered and supports a wide range of input voltages. The NodeMcu V3 ESP8266 is a versatile solution for developing WiFi-based projects with a reliable and high-speed communication interface.

Specifications:

Wireless Standard: 802.11 b/g/n
Operating Modes: STA / AP / STA + AP
Built-in TCP/IP Protocol Stack: Supports multiple TCP Client connections (5 MAX)
Ports: D0 ~ D8, SD1 ~ SD3 (GPIO, PWM, IIC, etc.), AD0 (1 channel ADC)
Power Input: 4.5V ~ 9V (10V MAX), USB-powered
Current:
Continuous transmission: ≈70mA (200mA MAX)
Standby: <200uA
Transfer Rate: 110-460800bps
Communication Interface: UART / GPIO data communication
Remote Firmware Upgrade: OTA
Smart Link Smart Networking Support
Working Temperature: -40°C ~ +125°C
Drive Type: Dual high-power H-bridge driver
